- 1
EFFICIENT
Energy saving drive
Advanced inverter regulation matches air supply to demand, cutting power consumption by up to 35% during frequent load and unload operation while maintaining stable pressure.
REMOTE CONTROL
Smart control system
The Airlogic2 T touch controller enables intelligent monitoring, connectivity and precise compressor management for efficient, secure and user‑friendly operation.
TECHNOLOGY
Robust motor design
Oil‑cooled permanent magnet iPM motor rated IP66 ensures long‑term reliability with excellent protection against dust and water ingress in harsh environments.
iPM technology for reliable performance
The KAS series is equipped with an oil‑cooled interior Permanent Magnet (iPM) motor designed to deliver high efficiency across the entire operating range. The iPM design minimizes energy losses and maintains high performance even at low speeds, making it the ideal match for fluctuating demand and high-efficient operations.
Its compact and robust design reduces heat generation, improves reliability and extends motor lifetime. With IP66 protection against dust and water, the iPM motor ensures stable and efficient operation in demanding industrial environments.
Why KAS series 7.5-22 stands out
By continuously adjusting motor speed to actual air demand, the KAS compressors significantly reduce wasted energy. This results in measurable electricity savings, especially in applications with variable consumption profiles, helping operators control operating expenses.
Additional benefits include stable pressure control, reduced mechanical stress and extended component life. Together, these advantages deliver long‑term reliability, predictable performance and a strong return on investment across the full 7.5-22 kW range.
- Inverter-driven screw compressor
- Capacity range: 0.43-4.1 m³/min
- Power: 7.5-22 kW
- Noise: 68-70 dB(A)
- Airlogic² T touch controller
- Real-time monitoring and trend analysis
- Energy savings up to 35%
Get in touch today!
Contact us today to learn more about this product or any other compressed air solution for your operations. Our experts are ready to assist you in finding the perfect compressor solution to meet your specific needs. Enhance your efficiency, reduce your costs, and invest in a reliable compressor that will serve you for years to come. Get in touch now and take the first step towards superior performance and energy savings.
Technical data
INSTALLED POWER
7.5-22
The KAS range covers 7.5 to 22 kW, available in 400V/50Hz and 380V/60Hz variants.
FAD
4.1
Delivers airflow up to 4.1 m³/min to meet diverse industrial requirements.
PRESSURE
10.5
With pressure options ranging from 7 to 10.5 bar, the KAS PV provides flexibility and efficiency to meet specific operational needs.
| Model | Pressure options (bar) |
Capacity (m³/min) |
Motor power (kW) |
Noise level (dB(A)) |
|---|---|---|---|---|
| KAS8PV | 7-8.5 10-10.5 |
0.49-1.25 0.43-1.1 |
7.5 | 69-70 |
| KAS11PV | 7-8.5 10-10.5 |
0.55-1.93 0.43-1.62 |
11 | 69-70 |
| KAS15PV | 7-8.5 10-10.5 |
0.7-2.5 0.7-2.1 |
15 | 68-69 |
| KAS22PV | 7-8.5 10-10.5 |
1.2-4.1 1.1-3.4 |
22 | 69-70 |
For full technical specification and more information refer to product brochure
KAS series
KAS series
Full product range
