EFFICIENCY
Ultra‑High Efficiency
The IE5 permanent-magnet motor and two-stage compression technology deliver immediate and long-term savings by producing more air with less power.
FLEXIBILITY
Software Pressure Control
Pressure can be adjusted via software without mechanical changes, enabling instant adaptation to changing production requirements with zero downtime.
STABILITY
Precise Pressure Control
Advanced VSD technology maintains stable system pressure while eliminating unloaded operation, improving process accuracy and overall system reliability.
Advanced two‑stage airend technology
The HS series two-stage airend compresses air in two optimized stages, with intercooling between stages, significantly reducing internal leakage and compression losses. This advanced airend design delivers more air with less energy compared to conventional single-stage airends, ensuring superior efficiency, stable performance, and long-term reliability in demanding industrial applications.
Why HS series stands out
The HS series delivers superior efficiency and adaptability through its IE5 permanent-magnet motor, two-stage compression design, and advanced VSD control, ensuring immediate energy savings and long-term cost reduction. Software-based pressure adjustment, intelligent cooling control, and stable pressure output make it a quiet, durable, and future-ready solution for demanding and evolving industrial environments.
- Capacity: 2.4-30 m³/min
- Power Output: 37-160 kW
- Noise Level: 63-80 dB(A)
- Efficiency: 77-84%
- Controller: advanced 7-inch multilingual controller
- Power Supply Specifications: 380-440 V, 50/60 Hz
Get in touch today!
Contact us today to learn more about this product or any other compressed air solution for your operations. Our experts are ready to assist you in finding the perfect compressor solution to meet your specific needs. Enhance your efficiency, reduce your costs, and invest in a reliable compressor that will serve you for years to come. Get in touch now and take the first step towards superior performance and energy savings.
Technical data
MOTOR EFFICIENCY
IE5
An IE5-class permanent-magnet motor maximizes electrical efficiency across the full operating range, enabling both immediate energy savings and a long-term reduction in total cost of ownership.
COMPRESSION EFFICIENCY
2‑stage
The two-stage airend efficiently compresses air with intercooling, reducing internal leakage and losses while delivering higher overall efficiency than conventional single-stage systems.
PRESSURE STABILITY
±0.1
Advanced VSD control maintains highly stable system pressure within a narrow range, eliminating unloaded operation and enhancing downstream process accuracy and product quality.
| Model | Pressure options (bar) | Free Air Delivery | Installed power (kW) | Air outlet | ||
|---|---|---|---|---|---|---|
| 7 bar | 8 bar | 9 bar | ||||
| HS50PV |
7-9 | 2.4-7.5 | 2.4-7.3 | 2.4-7 | 37 | 40A |
| HS75PV | 7-9 | 3.6-11.4 | 3.6-10.8 | 3.6-10.1 | 55 | 50A |
| HS100PV | 7-9 | 4.8-15.4 | 4.8-14.7 | 4.8-14 | 75 | 50A |
| HS125PV | 7-9 | 6.3-20.6 | 6.3-19.6 | 6.3-18.5 | 93 | 65A |
| HS150PV | 7-9 | 7.0-23.3 | 7.0-22 | 7.0-21.8 | 110 | 65A |
| HS175PV | 7-9 | 9.0-29 | 9.0-27.1 | 9.0-26.6 | 132 | 80A |
| HS200PV | 7-9 | 10.3-33 | 10.3-30.9 | 10.3-30 | 160 | 80A |
For full technical specification and more information refer to product brochure
