Efficiency
Energy efficient
The 3-in-1 stainless steel plate exchanger minimizes losses and boosts thermal efficiency, giving stable dew points and lower power use.
Durability
High lifecycle
Robust stainless components resist corrosion, ensuring long‑term performance, stable operation, and reliability over time.
Control
Smart monitoring
Digital controls offer clear dewpoint indication and drain valve management, simplifying maintenance and daily operation.
Stainless steel 3-in-1 system
The FLEX series technology centers on an integrated stainless‑steel plate heat exchanger that combines the evaporator, moisture separator, and reheater into a single compact module. This design enhances heat transfer efficiency, reduces pressure drop, and simplifies installation. The corrosion‑resistant stainless‑steel construction ensures long‑term performance, while the optimized refrigerant circuit maintains stable dew‑point control across varying load conditions.
Why the FLEX series stands out
The FLEX series combines high energy efficiency, compact design, and long‑term reliability. Its stainless‑steel 3‑in‑1 heat exchange system ensures stable dew‑point performance while reducing pressure loss and simplifying installation. Designed to minimize energy consumption and maximize uptime, the FLEX series delivers consistently clean compressed air for a wide range of industrial applications.
- Stainless steel plate heat exchanger
- 3-in-1 integrated module
- Digital controller with dewpoint indicator and drain management
- High-efficiency condenser on larger models
- Compact footprint
- Electronic drain valve configuration
- Alternative refrigerant selections
- Enhanced monitoring options
- Custom installation adaptations
Get in touch today!
With so many air treatment products available, finding the right solution can seem challenging. Our specialists are here to simplify the process and deliver options that match your exact requirements. Get in touch with us for expert advice and tailored recommendations.
Technical data
Capacity
61.38
FLEX models handle up to 61.38 Nm³/min under conditions, supporting demanding industrial compressed air systems.
Pressure
16
FLEX models operate at pressures up to 16 bar, ensuring compatibility with high-performance air networks.
Power
9.1
The FLEX series consumes up to 9.1 kW, supporting reduced operating costs and efficient duty cycles.
| Model | Power consumption (kW) |
Ambient temperature (°C) |
Nominal flow rate (Nm3/min) | Power (V/Ph/Hz) | Connection size | |||
|---|---|---|---|---|---|---|---|---|
| Inlet temperature (°C) | ||||||||
| 32 | 35 | 38 | 45 | |||||
| FL75X | 0.52 | 38 | 3.36 | 3.03 | 2.73 | 2.07 | 220/1/60 | 1' |
| FL100X | 0.65 | 38 | 4.31 | 3.89 | 3.5 | 2.66 | 1' | |
| FL200X | 0.86 | 38 | 8.4 | 7.58 | 6.83 | 5.19 | 2' | |
| FL350X | 1.2 | 38 | 14.32 | 12.92 | 11.64 | 8.85 | 2' | |
| FL425X | 1.86 | 38 | 17.39 | 15.7 | 14.14 | 10.75 | 2' | |
| FL600X | 2.55 | 38 | 25.34 | 22.87 | 20.6 | 15.66 | 2 1/2' | |
| FL800X | 5.6 | 38 | 34.56 | 32.32 | 28.1 | 20.79 | 380/3/60 | 3" |
| FL1250X | 8.9 | 38 | 52.52 | 49.11 | 42.7 | 31.6 | 4" | |
| FL1500X | 9.1 | 38 | 61.38 | 57.39 | 49.9 | 36.93 | 4" | |
For full technical specification and more information refer to product brochure
